A box-type air compressor is a compact and enclosed unit designed for efficient and portable operation in various industrial and construction settings.
Diesel Box Air Compressor Advantages
Whether you need to move on site or prefer a stationary solution. Professionally manufactured air compressors that offer a range of options suitable for a variety of applications. Box air compressors have the advantages of compact appearance, quietness, stability, high performance and a long life.
Take a look at a few of our products below
Full range of box type diesel air compressors with specifications
< scroll on mobile >
|
MODEL |
FREE AIR DELIVERY |
PRESSURE |
ENGINE |
DIMENSIONS (mm) |
WEIGHT (kg) |
AIR OUTLETS |
|---|---|---|---|---|---|---|
|
CF100B-7 |
100CFM/2.8M³/MIN |
7BAR/101.5PSI |
ISUZU JE493YB |
1880*915*1230 |
820 |
2x3/4" |
|
CF120B-7 |
120CFM/3.4M³/MIN |
7BAR/101.5PSI |
ISUZU JE493YB |
1880*915*1230 |
830 |
2x3/4" |
|
CF130B-7 |
130CFM/3.7M³/MIN |
7BAR/101.5PSI |
ISUZU JE493YB |
1880*915*1230 |
830 |
2x3/4" |
|
CF185B-7 |
185CFM/5.2M³/MIN |
7BAR/101.5PSI |
FAW 4DW91-56G2 |
2100*980*1100 |
930 |
3x3/4" |
|
CF190B-7 |
190CFM/5.4M³/MIN |
7BAR/101.5PSI |
ISUZU JE493ZYA |
2100*980*1100 |
930 |
3x3/4" |
|
CF275B-7 |
275CFM/7.8M³/MIN |
7BAR/101.5PSI |
ISUZU JE493ZLYA |
2280*1224*1260 |
1100 |
2x3/4" + 1x1-1/4" |
|
CF375B-7 |
375CFM/10.6M³/MIN |
7BAR/101.5PSI |
CUMMINS 4BTA3.9-C125 |
2657*1355*1466 |
1850 |
3x3/4" + 1x2" |
|
CF400B-7 |
400CFM/11.3M³/MIN |
7BAR/101.5PSI |
CUMMINS 4BTA3.9-C125 |
2657*1355*1466 |
1850 |
3x3/4" + 1x2" |
|
CF550B-7 |
550CFM/15.5M³/MIN |
7BAR/101.5PSI |
CUMMINS 6BTA5.9-C180 |
2970*1350*1465 |
1920 |
3x3/4" + 1x2" |
|
CF750B-7 |
750CFM/21.1M³/MIN |
7BAR/101.5PSI |
CUMMINS 6CTA8.3-C260 |
3600*1750*1900 |
3600 |
1x3/4" + 1x2" |
|
CF830B-7 |
830CFM/23.4M³/MIN |
7BAR/101.5PSI |
CUMMINS 6LTAA8.9-C360 |
3918*2200*2260 |
4200 |
1x3/4" + 1x2" |
|
CF1800B-7 |
1800CFM/50.7M³/MIN |
7BAR/101.5PSI |
CUMMINS QSZ13-C550 |
3600*1950*1900 |
7155 |
1x3/4" + 1x2" |
|
CF80B-10.5 |
80CFM/2.3M³/MIN |
10.5BAR/152.25PSI |
ISUZU JE493YA |
1880*915*1230 |
830 |
2x3/4" |
|
CF100B-10.5 |
100CFM/2.8M³/MIN |
10.5BAR/152.25PSI |
ISUZU JE493YA |
1880*915*1230 |
830 |
2x3/4" |
|
CF210B-10.5 |
210CFM/5.9M³/MIN |
10.5BAR/152.25PSI |
ISUZU JE493ZLYA |
2280*1224*1260 |
1100 |
2x3/4" + 1x1-1/4" |
|
CF390B-10.5 |
390CFM/11M³/MIN |
10.5BAR/152.25PSI |
CUMMINS 6BT5.9-C150 |
2970*1350*1465 |
1920 |
3x3/4" + 1x2" |
|
CF460B-10.5 |
460CFM/13M³/MIN |
10.5BAR/152.25PSI |
CUMMINS 6BTA5.9-C180 |
2970*1350*1465 |
1920 |
3x3/4" + 1x2" |
|
CF535B-10.5 |
535CFM/15M³/MIN |
10.5BAR/152.25PSI |
CUMMINS QSB5.9-C210 |
2970*1350*1465 |
1920 |
3x3/4" + 1x2" |
|
CF655B-10.5 |
655CFM/18.5M³/MIN |
10.5BAR/152.25PSI |
CUMMINS 6CTA8.3-C260 |
3600*1750*1900 |
3600 |
1x3/4" + 1x2" |
|
CF780B-10.5 |
780CFM/22M³/MIN |
10.5BAR/152.25PSI |
CUMMINS 6CTA8.3-C260 |
3600*1750*1900 |
3600 |
1x3/4" + 1x2" |
|
CF830B-10.5 |
830CFM/23.4M³/MIN |
10.5BAR/152.25PSI |
CUMMINS 6LTAA8.9-C360 |
3600*1950*1900 |
4200 |
1x3/4" + 1x2" |
|
CF1200B-10.5 |
1200CFM/33.8M³/MIN |
10.5BAR/152.25PSI |
CUMMINS QSZ13-C550 |
3918*2200*2260 |
7155 |
1x3/4" + 1x2" |
|
CF1600B-10.5 |
1600CFM/45M³/MIN |
10.5BAR/152.25PSI |
CUMMINS QSZ13-C550 |
3918*2200*2260 |
7155 |
1x3/4" + 1x2" |
